In the core processes of constructing and calibrating precision optical systems, the accurate establishment of an infinite optical axis forms the foundation of system performance. By generating highly collimated parallel light beams, collimators provide an irreplaceable reference for optical axis alignment, focal length measurement, and optical assembly. The core application scenarios supporting cutting-edge equipment across multiple fields are detailed below:

.

.

1.Military Industry: The Precision Lifeline of Combat Effectiveness

.

• Optical Axis Calibration for Missile Seeker: The deviation between the optical axis of an infrared/laser seeker and the mechanical axis of the missile body must be controlled within 0.5 arcseconds; otherwise, it will lead to fatal miss distance. Collimators simulate infinite targets, and combined with high-precision turntables and autocollimators, achieve sub-arcsecond (<1″) coaxial alignment between the optical axes of multi-spectral channels and the mechanical axis, ensuring precise strike capability.
• Multi-Spectral Coaxial Calibration for Airborne Electro-Optical Pods: An optical axis deviation exceeding 30 μrad among multi-sensors such as visible light, infrared, and laser rangefinder will result in target positioning failure. Collimators generate multi-band parallel beam arrays, and through micro-displacement adjustment mechanisms, achieve a spatial alignment accuracy of 5 μrad for the optical axes of each channel, ensuring the spatiotemporal consistency of battlefield situation awareness data.
• Zero Calibration for Tank Observation and Sight Systems: Mismatch between the bore axis and the optical axis of the thermal imager will cause fire deviation. Collimators construct virtual targets, and combined with electronic inclinometers, achieve dynamic calibration of biaxial spatial angles in a moving base environment, with a calibration residual ≤ 0.1 mil (≈ 0.36 arcminutes).

2.Aerospace Industry: The Precision Foundation of the “Eye in Space”

• On-Orbit Calibration Reference Source for Satellite Multi-Spectral Cameras: Spaceborne cameras are disturbed by launch vibration and space thermal environments, requiring optical axis stability better than 1 μrad. As the core of ground calibration systems, collimators establish an initial optical axis coordinate system for detectors of each band through diffraction-limited (λ/15) collimated beams, supporting the reference traceability of on-orbit laser calibration modules.
• Assembly and Alignment of Primary and Secondary Mirrors for Deep-Space Telescopes:To ensure the diffraction-limited resolution (0.01 arcsecond level) of 30-meter-class telescopes, the confocal deviation of the optical axes of the primary and secondary mirrors in the Cassegrain system must be strictly controlled within a wavefront error of λ/15 (≤ 42.2 nm RMS in the visible band). A large-aperture collimator with Φ≥800 mm is used to generate a reference beam with λ/30 collimation (wavefront distortion < 21 nm). A high-density Shack-Hartmann sensor (32×32 sub-apertures) analyzes optical axis offset in real time at a 500 Hz bandwidth, and a six-degree-of-freedom nano-displacement stage (step accuracy 1 nm) is linked to dynamically compensate for the pose errors of the mirror group.
• Industrial Manufacturing: Guardian of Mass Production Precision – Transmitting-Receiving Optical Axis Matching for LiDAR: A coincidence deviation exceeding 0.1° between the laser transmitting field of view and the receiving field of view will cause point cloud voids. Collimators simulate targets 200 m away, drive six-dimensional adjustment mounts to calibrate the relative poses of transmitting and receiving modules, and achieve a field-of-view center alignment accuracy of ±0.02°, meeting the mass production consistency requirements of automotive-grade LiDAR.
• Active Alignment (AA Process) for Mobile Phone Multi-Camera Modules: An optical axis deviation exceeding 15 μm among wide-angle/telephoto/ToF lenses will cause ghosting in fused images. Collimator arrays generate multi-angle infinite virtual images, and combined with high-precision machine vision systems, perform real-time closed-loop correction on nano-displacement stages, achieving an optical axis tolerance of ±3 μm (3σ) and supporting a yield rate of over 99.5% for 100-megapixel modules.
• Wavefront Detection Reference for Lithography Machine Projection Objectives: The wave aberration of EUV lithography objectives must be controlled below 0.5 nm RMS. Collimators output 13.5 nm extreme ultraviolet light with λ/50 collimation, providing a reference wavefront for interferometers, and realizing nano-precision closed-loop control for objective system assembly and thermal deformation compensation.

3.Civil Scientific Research: The Optical Cornerstone of Exploring the Unknown

• Six-Degree-of-Freedom Calibration for Secondary Mirrors of Astronomical Telescopes: The position deviation of secondary mirrors in large segmented-mirror telescopes (e.g., ELT) must be < 50 nm. Collimators generate stellar point sources, and through curvature sensing and phase retrieval algorithms, drive piezoelectric ceramic actuators to achieve mirror co-phasing adjustment, reaching wavefront consistency of λ/40 (@633 nm).
• Coaxiality Detection for Endoscopic Imaging Fiber Bundles: Microradian-level deflection of a single fiber will cause honeycomb distortion in images. Collimators output a uniform illumination field, and combined with microscope objectives and Fourier analysis, quantify the imaging coaxiality deviation of fiber bundles to < 0.1 mrad, ensuring millimeter-level restoration accuracy of vascular textures in minimally invasive surgery.
• Transmitting-Receiving Axis Calibration for Quantum Communication Telescopes: Single-photon level signal reception requires transmitting-receiving optical axis matching accuracy at the μrad level. Collimators establish a reference axis for satellite-ground links, and through polarization maintenance and wavefront shaping technologies, achieve an optical axis alignment residual ≤ 2 μrad at a distance of 800 km, supporting a quantum key distribution bit error rate < 1%.

4.Conclusion
